ANTI BANDIT DOORS

(Bullet Proof)

THE DOOR GROUP’s Anti Bandit Door range consist of the following categories:

  • Anti-bandit G1 (9mm Parabellum)
  • Anti-bandit G2 (.357 Magnum)
  • Anti-bandit G3 (AK47)
Anti Bandit Doors (Bullet Proof)

G1

G1 (9mm Parabellum) Small arms

Ammunition Weight of Projectile Weapon Velocity
22 High Velocity Solid Lead 2.6g .22 long rifle 330
.38 Lead 10.2g .38 revolver 260
9mm Full Metal Jacket 8.0g 9mm 4" Barrel Revolver (Std. Velocity) 360
9mm Full Metal Jacket 8.0g 9mm 4" Barrel Revolver (Std. Velocity) 440
.44 Lead Point 15.6g .44 magnum Revolver 425
.357 Semi Metal Jacket 10.2g .357 Magnum Revolver 425
.357 Armour-Piercing 9.0g .357 Magnum Revolver 420

G2 - All above plus:

G2 (.357 Magnum) High Security Area

This door is manufactured for the entrances of buildings and secured areas

Ammunition Weight of Projectile Weapon Velocity
AK 47 Ball 7.9g AK 47 Rifle 748
7.62(.308)Full Metal Jacket 9.7g Nato FN l Rl Rifle 850
5.56 (.223) Full MEtal jacket 3.56g R4 Rifle 960

G3 - All above plus:

G3 (AK47) High Security Area

This door is manufactured for high security areas to withstand the penetration of armour-piercing weapons (R1 &R4)

Ammunition Weight of Projectile Weapon Velocity
5.56 Armour-Piercing 3.56g R4 Rifle 960

FRAMES

The frames are manufactured from 3mm steel. Either in mild steel with factory coated red oxide or pre-galvanized steel. The rebate section measures 50 x 25mm

HINGES

The doors are fitted to the frame with a heavy duty continuous hinge. This eliminates the gap between the door and the frame, preventing the door from being pried open or removed.

VIEWING PANELS

A viewing panel consists of a 300mm x 200mm bullet resistant glass (38mm) in a metal frame. It is designed so that the frame cannot be unscrewed from the attack side of the door.

IRONMONGERY

The doors are fitted with a single or double (depending on requirements) security lock with key operation externally, and thumb turn release internally. Pull handles are fitted to both sides of the door (300mm)

Finish

The finish of the door would be to the Architects requirements.

INSTALLATION

The door and frame unit must be installed square true and plumb with the door in the closed position. The bottom leading edge of the door must be wedged to support the vertical load of the door on the frame. The wedge should not be removed until the brickwork is cured

STANDARD DOOR SIZES

2032X 813 / 900 / 1000. Anti-Bandit Doors are not manufactured as a double leaf.
