Steel Doors & Frames

Material:

Steel frames are available in the following:

Single

Double

Fanlight

Removable transom

Mullion

Steel Doors & Frames

FRAMES:

Finish: Red oxide (mild steel)

Wall Thickness: Standard 90mm, 115mm, 140mm and 230mm. Frames can be manufactured to a specific wall thickness.

Frame Fastenings:

- Lugs for brickwork,

- Boltfix for openings already completed

- Drywall fixing



Floor Finish: Non screeded frames for completed concrete floors.

Screed frames for floors still to be cast.

Rebate:

Single or double rebate . Rebate size 42 x 12mm.

Frame Sizes:

Standard

  • 2032 x 813/915
  • 2032 x 1511

Cupboard sizes:

  • 2032 x 762/610
  • 2032 x 1511/1206
  • 457 x 762/610
  • 457 x 1511/1206

Special sizes manufactured on request

  • Steel Doors
  • Steel Doors
Handing

Handing:

Always stand on the side of the frame where the door is opening towards you If the hinges are on the left-hand side, the frame is Left Hand Opening.

DOORS

Chawl Door

Chawl Door

This is a combination Door. It is sold as a door and a frame. The panels are braced/ fluted to give additional rigidity.

Chawl Door quick release

Chawl Door quick release

 LOUVRE PANELS

Louvre panels lined on the inside with a vermin proof mesh. Manufactured from 1.6mm steel (red oxide mild steel / Pre galvanized steel)

Type ALU: Screen size 900mm(h) x 747mm(w)

Type BLU: Screen size 1590mm(h) x 747mm(w)

Complete with rebated frame surround for installation in walls are also available.
